.| 4th yr

Mechanical Engineering (‘27) student @ Boston University with a focus on Design and Product Development.

Material ScienceSolidWorksExcelMATLABPythonMachiningThermodynamicsFluid MechanicsMachine DesignStaticsDynamicsAerodynamicsC++LeadershipRhinoceros 3DElectrical CircuitsMechanics of MaterialsStatistic and Machine Learning
01 — About Me
Brett Womack
ME Student · Boston, MA
4th Year GPA 3.4
Open for Summer 2027

I'm a mechanical engineer undergrad who has always been drawn to how things work and why they're built the way they are. Aerospace was my first interest in engineering as my grandfather worked for Pan American Airlines and my aunt worked at Tinker Air Force Base which made airplanes a recurring interesting part of my life. It pushed me toward science early on, because I wanted to understand how airplanes fly and the forces that make it possible.

By 5th and 6th grade, I was the first and only student in my school's aircraft club, learning about lift, drag, and pressure differences long before I knew what "engineering" really meant. Science fairs became my place to experiment, and in 6th grade I built my own wind tunnel and tested all kinds of airfoils just because I was genuinely curious.

From there, engineering just became the way I saw the world. Through middle and high school, I took every engineering class I could and spent years learning CAD 3D modeling softwares.

Now, as I look toward Summer 2027 opportunities, I'm driven by that same mix of curiosity, hands‑on building, and the excitement I felt the first time I watched air move through the wind tunnel I built as a kid.

02 — Projects

Featured work

CLICK TITLES TO SEE MORE!

More projects

Soap Dispenser project
ENG EK 210 · Principles of Engineering Design

Automated Soap Dispenser

Designed a contactless soap dispenser with a sensor-driven actuator, modular waterproof housing, and optimized ergonomics; led mechanical design and supported circuit integration.

OnShapeTinkerCad3D PrintingSolderingC++
Temperature Sensing Box
ENG Ek 131 · Introduction to Engineering

Temperature Sensing Box

Built an Arduino-based temperature monitor with real-time alerts (LED, buzzer, LCD) for out-of-range conditions; handled wiring, enclosure design, and code, and validated system performance.

OnShapeTinkerCad3D PrintingArduino
Armadillo Zoo Enrichment Box
ENGR 1413 · Pathways to Engineering Thinking

Armadillo Zoo Enrichment Box

Designed and prototyped a dig-box enrichment system for a three-banded armadillo, improving accessibility and durability to support natural foraging behavior and visitor engagement.

SolidWorksMilling3D Printing
Temperature Sensing Box
EK 301 · Statics

Truss Design Project

Designed and optimized a cost-efficient truss using computational analysis to maximize strength and minimize bending; built and tested a 31-inch prototype meeting load and design constraints.

Static AnalysisSolidWorksMATLAB
4 bar
ME 360 · Electromechanical Design

4 - Bar Mechanism

Analyzed a four‑bar linkage to determine torque requirements and bearing reaction forces across different crank angles and speeds.

SimulationSolidWorks3D Modeling
Trashcan
ME 360 · Electromechanical Design

Trashcan Assignment

Designed a 4‑bar mechanism to move a trash tray without tipping, using Math Illustrator for geometry and SolidWorks for the full motion study.

Math IllustrationsSolidWorksSimulation3D Modeling
Projects completed
8+
Engineering designs
built & tested
Tools mastered
20+
CAD, simulation,
lab & code
03 — Skills

My toolkit

🖥️
CAD & 3D
  • SolidWorks
  • Rhinoceros 3D
  • OnShape
  • 3D printing
  • Technical drawings + GD&T
💻
Simulation
  • XFoil
  • OpenVSP
  • MATLAB
  • Python (NumPy, Matplotlib)
  • Excel + data analysis
🔧
Lab & Shop
  • Manual lathe & mill
  • CNC machining basics
  • Precision measurement
  • Soldering
  • Lab instrumentation
📐
Engineering
  • Thermodynamics
  • Material Science
  • Fluid mechanics
  • Statics & dynamics
  • Machine design
04 — Experience

Where I've been

2026 — Now
Internship

Engineer Intern

Robert Derector Telecommunications · New York, NY

Current Summer Internship.

AutoCADRivetExcelSite Visits & Hands On Experience
2023 — Now
Part Time Temp.

Data Analyst

University of Pennsylvannia Dental School · Remote

Led reconciliation of EFT discrepancies and denial management workflows; automated 835 processing and clearinghouse tracking to improve posting accuracy and reduce resubmission delays.

axiUm Dental SoftwareExcelCrystal Reports
2024 — Now
Student Employee

Gym Facilities Supervisor

Boston University FitRec · Boston, MA

Delivered high-volume customer support and front-desk operations; guided patrons on equipment use and managed daily transactions with accurate cash handling; recognized as 2× Employee of the Month.

Customer ServiceStudent ServicesTeamwork
HI
05 — Contact

LET'S
BUILD
SOMETHING.

I'm actively looking for entry-level job opportunities for Summer / Fall 2027 in product development, design, aerospace, or anywhere I can apply and expand my engineering skills to build meaningful, well-designed solutions..

Open to opportunities
